heroal VS sun shading system
Use of heroal VS in the exterior view

heroal VS

Textile sun protection

Thanks to its extremely narrow guide rails and small box size, the textile sun protection heroal VS can be ideally integrated into the look of your house. heroal VS Z can be fully plastered in, hence disappears invisibly into the façade. But the textile screen heroal VS can also be surface-mounted, and, thanks to its filigree design, is also suitable for a retrofit at a later date. The wide range of sun protection fabrics, reducing sun and UV radiation by up to 98 %, as well as versatile design options enable you to perfectly adapt heroal VS to your needs and requirements.

  • end strip-guided
  • for low wind load requirements
  • from almost transparent to blackout (up to 98 %)

    Product Details

  • More product details

    Sustainability

    Sun protection systems provide for healthy living and working conditions. They create a pleasant room climate on hot days and help to save air conditioning and heating costs, as natural light can be individually controlled as needed. Sun protection systems from recycled aluminium and high-quality textiles are resistant to the elements and stand out for their high material stability and extreme durability.

    Comfort

    The heroal VS offers ideal protection from glare, prying eyes, heat and UV radiation. The heroal VS can be controlled at the push of a button on a remote control, via a manual switch on the wall, or via an app. Also, the textile screen can be integrated into smart home systems. Many different motorisation options ensure an easy planning and installation.

    Design

    The aluminium parts of the heroal VS are coated with the highly weather-resistant heroal hwr powder coating – for perfect colour uniformity with heroal systems for windows, doors, sliding doors, curtain walls and canopies. The standard portfolio of more than 250 different textiles offers a great freedom of design. Elements up to 5 m high and 5 m wide, with a maximum area of 15 m², can also be created with a small box, providing for unobtrusive designs - even for a retrofit at a later date in combination with a surface-mounted box.

    Everything from one source

    heroal offers products for the building shell from one source: heroal sun protection systems are compatible with heroal systems for windows, doors, sliding doors, canopies and curtain walls, and are perfectly matched in terms of design and function. Thanks to their colour uniformity and well-thought out design details, heroal systems can be easily combined with each other and integrate seamlessly into the building shell.

  • Prospects

  • Dimensions & drawings

    Box

    Box type
    FME
    Box shape
    45°, 90°, HC N
    Box size [mm]
    85**, 95, 105, 125

    Element

    Max. Elementwidth [mm]
    5.000
    Max. Elementheight [mm]
    5.000
    Max. area [m2]
    15
