Sliding glass wall

Turn your patio roof into a weather-independent summer garden with the flexible, frameless sliding glass wall heroal S 20 C.

Sliding glass wall

Sliding glass wall for patio roofs and summer conservatories

Sliding glass walls offer both optimal protection against the weather and highest flexibility, enabling you to use your patio year-round and regardless of the weather – while at the same time providing a panoramic view of your garden. Thanks to the flexible sliding glass elements, you can open or close all or part of your patio roof – turning your patio roof into a summer conservatory in next to no time. With the frameless elements of a sliding glass wall by heroal, you do not only extend your living space, you also opt for excellent quality „Made in Germany“. Furthermore, the all-glass sliding wall system heroal S 20 C is perfectly designed to match the patio roof system heroal OR and harmoniously integrates into the looks of your patio roof. Convince yourself of the outstanding features of heroal sliding glass walls for patio roofs and summer conservatories now.

What’s so special about heroal sliding glass walls?

Frameless

Thanks to its frameless all-glass elements, the sliding glass wall heroal S 20 C provides for a panoramic view of the garden.

Comfortable

Integrated slide dampers and stoppers provide for a comfortable and safe opening and closing of the elements, acting like a cushion while the elements are automatically pulled into their final position.

Barrier-free

Perfect accessibility of your covered patio is guaranteed through a barrier-free threshold, which is also available for systems with 5 tracks.

All-glass sliding wall heroal S 20 C

The non-insulated all-glass sliding wall system heroal S 20 C for covered outdoor areas stands out for its maximum flexibility and highest quality. The frameless elements and a barrier-free threshold lend this wall system its very elegant design and maximum light transparency. Slide dampers ensure a safe and comfortable opening and closing, acting like a cushion while the individual elements of the wall are automatically pulled into their final position. In addition, element carriers and durable stainless steel guide rails guarantee a durable, very comfortable operation. The integrated dirt drain makes it very easy to maintain and clean the wall. Thanks to the multi-track frame profiles offering up to 5 tracks, heroal sliding glass walls offer great flexibility through numerous opening options. The sliding glass wall may be opened to one or both sides. Surfaces of up to 7,200 x 2,500 mm can easily be created with heroal S 20 C. The sliding elements may have an individual width between 60 and 1,200 mm.

The all-glass sliding wall system heroal S 20 C is perfectly designed to match the patio roof system heroal OR. It harmoniously integrates into the look of your patio roof and is also suited for a retrofit at a later date. Get more information about the patio roof system heroal OR now.

heroal S 20 C > Patio canopy system heroal OR >

Components of the sliding glass wall heroal S 20 C

Maximum transparency thanks to frameless sashes.

Reduction of draughts through transparent sealing strips.

Elegant, flush pulls made from brushed stainless steel.

Perfect operation and running since elements can be professionally adjusted.

Ground level threshold combined with effective drainage system heroal DS.

Perfect ease of use thanks to additional slide dampers.

Maximum element width up to 7.2 m.

The most important features in more detail

  • Minimal draughts

    When the sliding wall is closed, transparent sealing strips noticeably reduce draughts. The sealing strips provide for ideal tightness, closing the gap between two glass elements, also between elements coming from left and right. Thanks to their subtle design and transparent material, the sealing strips unobtrusively integrate into the sliding glass wall. Since they are highly resistant to UV radiation, they are ideally suited for outdoor use.

  • Perfect running

    The slide mechanisms of the sliding glass wall heroal S 20 C can be adjusted precisely, and guarantee a smooth running of the individual glass elements in the stainless steel rail. The sliding elements can be moved with ease, sliding in the rail without jolting or bumping.

  • Perfect ease of use

    Integrated sliding dampers automatically draw the glass elements into their final position, smoothly, one by one. Any uncontrolled bumping due to an excessive sliding speed is prevented and thus the element closes very quietly. Also, damages to the glass and the complete sliding system, due to moving the elements too fast, are prevented. Closing the sliding wall using dampers also reduces the risk of finger bruises or similar injuries.

  • Barrier-free threshold with effective drainage

    The sliding glass wall heroal S 20 C offers you barrier-free threshold solutions according to German Industry Norm DIN 18040 1/2. The drainage system heroal DS can be integrated; its design is perfectly adapted to the sliding glass wall. It provides for an effective drainage, e.g. with driving rain or accumulating surface water. So you can feel perfectly protected on your patio at any time. The high-grade cover with a stainless steel look integrates harmoniously and matches the stainless steel rails of the sliding glass wall.

  • More security

    The heroal S 20 C sliding glass wall can be secured against unauthorized access with an additional locking set. After installation, the all-glass sliding system can be locked or unlocked by simply pressing the inside with your foot or hand.


Advantages of a sliding glass wall

Weather protection

Integrating a sliding glass wall into a patio roof or summer conservatory provides for an ideal protection against the weather and enables you to use your patio year-round. The all-glass sliding wall system heroal S 20 C protects against wind and driving rain. Thanks to the sliding elements of the glass wall, you can stay flexible and either open or close all or part of your patio roof.

Heat storage

Enjoy the warmth of the day after the sunset. With the glass elements of a sliding wall closed, you can turn your patio roof into a summer conservatory in next to no time, keeping the warmth of the day inside until the late evening.

Insect protection

Would you like to have a piece of cake in piece and quiet or end the evening on a cosy note on your patio? During the summer months, midges and wasps are uninvited guests on your patio. When you close the elements of a sliding glass wall, you are optimally protected against insects.

Flexible alternative to a conservatory

With a sliding glass wall, your patio roof turns into a garden room in next to no time. The combination of patio roof and sliding glass wall creates a summer conservatory, also referred to as cold or uninsulated conservatory, enabling you to enjoy your garden year-round.


FAQ

  • Where can I buy heroal sliding glass walls?

    heroal sliding glass walls are exclusively available from heroal specialist partners. To make sure that the sliding glass wall is perfectly adapted to your canopy, our experienced heroal specialist partners take care of the professional planning and installation. Use our heroal specialist partner search to find a fabricator near you easily and fast.

    Find a specialist partner >

  • Can I use heroal sliding glass walls also for canopies from other manufacturers?

    Sliding glass walls from heroal can be combined with all standard patio canopy systems, They can also be used as partition walls indoors.

  • Are heroal sliding glass walls also suitable for patio canopies made from wood?

    Non-insulated heroal sliding glass walls provide for flexible uses both indoors and outdoors and are also suitable for patio canopies made from wood.

  • Can heroal sliding glass walls be made to measure?

    The all-glass sliding wall system heroal S 20 C is customized to your requirements. Walls with 3, 4 or 5 custom-fit glass elements offer a wide range of design options to match your patio roof. The wide range of RAL chart colours, the exclusive Les Couleurs® Le Corbusier colours as well as the heroal Surface Designs (heroal SD) in wood, concrete or rust looks provide for freedom of design. Thus, the frame of the sliding glass wall can be designed to ideally match the looks of your house and patio roof. Use our specialist partner search to find a competent heroal fabricator near you.

    Find a specialist partner >

  • Can I also use heroal sliding glass walls as a solution for interior rooms?

    The moving glass wall heroal S 20 C can easily be integrated in outdoor areas, but also offers many options to create appealing interior solutions. Since the weight of the moving glass wall is carried by element carriers running in guide rails fixed to the floor, the sliding system heroal S 20 C is especially suited for suspended ceilings. The bottom guide rail can be mounted concealed in the floor and the walls. Combined with satin-finished glass or individually designed glass, walk-in closets, bathroom partitions or flexible partition walls for living areas can be created, for example.

Gallery

Advantages of heroal sliding glass walls at a glance

heroal sliding glass walls for patio roofs and summer conservatories stand out for their design, durability and flexibility. See for yourself. Our competent heroal specialist partners will be pleased to consult you – also on-site.

Brochure sliding glass wall

  • barrier-free threshold
  • frameless elements for maximum light transparency
  • 3-, 4- and 5-track frame profiles
  • easy cleaning due to integrated dirt drain
  • comfortable operation thanks to integrated slide dampers
  • flexible opening types
