heroal C 50 TC
Canopy heroal C 50 TC based on curtain wall system heroal C 50
The high-quality canopy heroal C 50 TC for upscale residential and project buildings can be created from the versatile curtain wall system heroal C 50. With a maximum overhang of 2,000 mm and an adjustable roof pitch, the canopy can be adapted to individual requirements. Thanks to the pressure strip screw connection with countersunk screws, identical profile machining as for heroal C 50, and the heroal system attachment technology, both manufacture and installation are easy and fast. The canopy is firmly attached to the curtain wall or building structure. Per mount, loads up to 6.5 kN are transferred. The slim profiles used for these elements, a 60 x 50 mm rafter profile and a 50 x 50 mm support profile, create subtle looks.
- Efficient fabrication using universal punch for curtain walls
- Large canopies with a depth of up to 2,000 mm possible
- Available in different colours and designs
