System extension for heroal roller shutter systems

Innovative solutions for greater efficiency, functionality and design freedom.

With its latest system enhancements, heroal offers an innovative range of roller shutters that combines efficiency, comfort, design and economy. New to the range: the heroal RS 37 SW and heroal 52 SW roller shutter slats with a tight winding design, ideal for compact box sizes. The system is co

With its latest system enhancements, heroal offers an innovative range of roller shutters that combines efficiency, comfort, design and economy. New to the range: the heroal RS 37 SW and heroal 52 SW roller shutter slats with a tight winding design, ideal for compact box sizes. The system is complemented by a versatile platform for angled end strips, tight guide rails against driving rain, the cost-effective heroal FMC box system and solar-powered operators. For maximum flexibility and simple, time-saving production, heroal roller shutter slats are available as pre-assembled roller shutter curtains – now also featuring the new system components.

Your benefits

Space-saving & versatile

The heroal RS 37 SW and RS 52 SW roller shutter slats, which roll up tightly, are ideal for small boxes. They enable compact, discreet solutions – perfect for front-mounted and top-mounted systems.

Certified with tightness against driving rain

heroal DRP guide rails offer protection against driving rain up to 600 Pa. Thanks to their modular design, they can be flexibly adapted to any building situation.

Efficient & flexible

The new platform for corner trims is suitable for Mini and Maxi systems. It simplifies installation and reduces the wide range of versions. Pre-assembled curtains enable particularly time-saving production.

An overview of all the latest products

heroal FMC blind system

The heroal FMC cover system offers particularly good economy for soffit installations with a visible front panel, thanks to its combination of roll-formed and extruded panels.

Integrated solar motor

The integrated solar motor from Somfy or Kaiser Nienhaus enables roller shutters to be operated sustainably without a separate power supply.

Tightly wound roller shutter slats

The heroal RS 37 SW and heroal 52 RS SW roller shutter slats, which wind tightly, allow for optimum use of the winding space and offer excellent performance characteristics.

heroal DRP guide rails, tightness against driving rain

The heroal DRP guide rail offers reliable protection against driving rain and is available in a wide range of versions – including a two-part version.

heroal corner trims

The new platform for corner end strips in the top-mounted/front-mounted kit makes installation easier and ensures an attractive completion for roller shutter systems.

Narrow-winding roller shutter slats

The heroal RS 37 SW and heroal RS 52 SW roller shutter slats impress with their tight winding and small barrel diameter – ideal for compact box sizes and space-saving system solutions. The optimised hook and pocket geometry ensures a secure slat connection, prevents individual slats from coming

The heroal RS 37 SW and heroal RS 52 SW roller shutter slats impress with their tight winding and small barrel diameter – ideal for compact box sizes and space-saving system solutions. The optimised hook and pocket geometry ensures a secure slat connection, prevents individual slats from coming unhooked and guarantees maximum light-tightness when closed. The slats are available as system components or as ready-made curtains, enabling cost-effective planning and simple installation.

Ideal for heroal RS 37 SW front-mounted boxes

The heroal RS 37 SW roller shutter slat is ideally suited for use in front-mounted boxes, but can also be flexibly integrated into all other box systems. With a visible height of 36.9 mm, a nominal thickness of 7.5 mm and a weight of 3.0 kg/m², it is wind-resistant and meets the wind load requirements of resistance class 3 for element widths of up to 2,500 mm.

  • Nominal thickness [mm]: 7.5
  • Viewing height [mm]: 36.9
  • Max. width [mm]: 3,300
  • Max. height [mm]: 3,500
  • Max. area [m²]: 7.0
  • Number of slats per 1 m of blind height [pcs.]: 27.1

heroal RS 37 SW >
Ideal for add-on units heroal RS 52 SW

The heroal RS 52 SW roller shutter slat is mainly used in top-mounted boxes, but can also be integrated into all other box systems. With a visible height of 52.3 mm, a nominal thickness of 13.4 mm and a weight of 3.7 kg/m², it offers high wind resistance and meets the wind load requirements of resistance class 3 for element widths of up to 3,500 mm.

  • Nominal thickness [mm]: 13.4
  • Viewing height [mm]: 52.3
  • Max. width [mm]: 4,500
  • Max. height [mm]: 3,800
  • Max. area [m²]: 10.0
  • Number of slats per 1 m of blind height [pcs.]: 19.1

heroal RS 52 SW >

heroal end slats

The new platform for angled end strips enables easy installation in both right- and left-hand roller applications in top-mounted and front-mounted boxes, and provides a flush box finish. The angled profiles can be combined with all Mini and Maxi end strips and attached using a clip-on system. Plastic glides ensure smooth running in the guide rail. New to the range is a shorter angled profile (11 mm) for use on balustrades, as well as additional right- and left roller variants of the Mini basic profile. An integrated slope with a drainage area prevents water build-up.

End slats >

MiniLR type II end slat
Maxi RR Corner Skirting Board

heroal DRP guide rail, tightness against driving rain

The heroal DRP platform offers versatile, tight guide rails against driving rain which, thanks to the integrated Norseal® sealing tape, are certified up to 600 Pa. They are compatible with the box ends of the heroal FMR, heroal FME, heroal FMB and heroal FMC insect screen systems. In addition to the standard version of the HTF-DRP guide rail, other versions with spacers are available to achieve a distance of 20 mm or 40 mm from the window. Furthermore, 10 mm spacer profiles are available, allowing for variable adjustment of the spacing. The heroal DRP range is complemented by a centre guide rail for integrated insect screen systems, as well as a two-part guide rail that eliminates the need for visible screws.

Guide rails >

HTF-DRP 2-piece set with cover and seal
HTF-DRP and seal
F-HTF-IS DRP and seal
F-HTF-K 40-DRP, 10-DRP spacer profiles and seal

heroal FMC roller shutter panels

The heroal FMC combination box system combines roll-formed and extruded panels for economical front-mounted installation. Box sizes ranging from 137 to 180 mm can be achieved, as well as box shapes with 20°, 45° and 90° angles. An adapter profile ensures a harmonious appearance and allows existing heroal FME panels to be used. The front flange increases stability and is ideal for applications with a visible front panel.

Roller shutter panels >

FMC 20° box system
FMC 45° box system
FMC 90° box system

Integrated solar motor

The integration of the Kaiser Nienhaus Easyline Solar (6 and 20 Nm) and Somfy RS 100 Solar iO (6, 10, 15 and 20 Nm) solar motors enables the sustainable operation of heroal roller shutter systems – without the need for an external power supply. There is a wide range of different roller shutter slat systems to choose from, with coverage widths between 37 and 52 mm. The control system uses radio signals and a remote control or a wall-mounted switch. Even with low levels of solar radiation, up to 100 operating cycles are possible. If required, the battery can be charged externally. Should the battery ever become completely discharged, it can also be recharged via an external interface.

Solar drive >

Finished roller shutter curtains

To ensure maximum flexibility and time-saving production, heroal roller shutter slats are also available as pre-assembled roller shutter curtains – comprising the slat system and end strip. With the expansion of the roller shutter portfolio, the range of ready-made curtains has also been extended. The new, close-winding heroal RS 37 SW and heroal RS 52 SW roller shutter slats are also available as heroal ready-made curtains. The configuration options have been optimised – including through the integration of the new angled end-strips and accessories such as quick-connectors, steel strip mountings and end-strip accessories. The revised colour scheme across the Basic, Trend and Exclusive ranges offers a wide variety of design options: from readily available classics to modern accent colours and exclusive custom colours. The convenient ordering process via the heroal Business Configurator ensures efficient workflows.

Finished roller shutter curtains >

Download the brochure

In our brochure, you will find all the information on the system enhancements and new features of heroal roller shutter systems.

Brochure: Roller Shutter Systems – System Extensions
