heroal S 42

Efficient and functional

The heroal S 42 sliding system is characterised by top quality combined with maximum efficiency with regard to energy and cost. A slim appearance, accessibility and comfort are just some of the performance features of the heroal S 42 sliding system. These features guarantee flexible installation as sliding windows or French doors in industrial and residential construction.


System dimensions

Profile depth [mm]

Frame profile
72 - 79
Leaf profile
38 - 42
Bar profile
38

Visible profile width [mm]

Frame profile
48
Leaf profile
68 / 72
Bar profile
68

System properties

Glass filling strength [mm]
28
Max. leaf weight [kg]
160
Max. leaf heights [mm]
2.600

Performance characteristics

4 Air permeability
>1,3* Heat insulation (Uw in W/m2K) / Profile width [mm]
8A Resistance to driving rain
C3/B4 Wind resistance
1-3 Soundproofing class
1 Operating forces

Extras

Tailored support for architects

In order to ensure all-inclusive support, heroal’s team of consultants offer advice across Germany. heroal’s technical support deals with all the questions you may have concerning windows, doors and curtain walls as well as roller shutters, sun protection and roller doors -if required, also on-site of your building project. Are you new to heroal? Get in touch with us today!

All information in the heroal Communicator

Our Communicator, heroal’s online workplace, always makes the current documentation available to you. Via the Communicator-App, you can get in touch with your architect’s consultant immediately.

  • Download test documents
  • Find product information
  • Readily available CAD data instantly
  • Download BIM data
  • Latest projects for reference
