heroal C 50 FP

The system solution for fire protection façades

The heroal C 50 FP fire protection curtain wall system requires a CE marking and has been tested in accordance with the EN 13501-2 standard as a curtain wall by the ift Rosenheim testing institute. All fire protection components are concealed within the construction, enabling an invisible transition to façade areas without protective requirements.

The fire protection curtain wall system can be expanded on the basis of the heroal C 50 façade to create a uniform EI 30 i<>o façade. Using the same basic profiles and a few additional components such as the patented Fireblock insulator, a façade offering a high level of safety can be created. This is subject to CE marking.


System dimensions

View width [mm]
50
Construction depth [mm]
95 - 185
Transom profile depth [mm]
60 - 190
Glass filling strength [mm]
22 - 44
Max. weight of filling element: [kg]
450

Performance characteristics

1,6 - 2,2 Thermal insulation [Uf in W/m2K] / Profile width [mm]
AE* Air permeability
RE 1050 Resistance to driving rain
2 kN/m2 Wind resistance
I5/E5 Impact resistance
EI 30 Fire resistance

* Air permeability < 0.5 m3/h m at pressure> 600 PA
